GW/A10-EDF W/EDF50 AIRPLANE KIT, PROPELLER AND MOTOR HAVE BEEN MODIFIED,

 SO THIS ITEM WILL BE  RECOVERED THE  RELEASING FORM NOW  ON.



GW/A10-EDF50 Series ( THE WARTHOG)

Length : 872 mm (34.3 in.)

Wing Span : 968 mm (38.1 in)

Wing Area : 13.95 dm (216 sq.in)

Empty Weight :

Flying Weight : 400~500 g (14.1~17.6 oz)

Wing Loading : 28.7~35.8 g/d㎡  (9.4~11.7 oz/sq.ft)

Power System : EDF-50

Propeller : EDF2030X5

Battery Required : 8N300~600mAh(NI-MH)

Servo : PICO / NARO

Receiver : R4PII / R6NII

Speed controller : ICS-300 above

Radio Required : 4-Channel radio



  • GW/A10-EDF/G  (Green color)

  • GW/A10-EDF/D (Desert color)

  • GW/A10-EDF/G8 (Gray color)



W/ EDF50 Duct Fan power system set.



AIRPLANE MANUAL _ A10PRODUCT ALBUM零件價目表

GW/A10-EDF55 Series ( THE WARTHOG)

Length : 872 mm (34.3 in.)

Wing Span : 968 mm (38.1 in)

Wing Area : 13.95 dm (216 sq.in)

Empty Weight :

Flying Weight : 470~520 g (16.6~18.3 oz)

Wing Loading : 33.7~37.2 g/d㎡  (11~12.2 oz/sq.ft)

Power System : EDF-55 (150~300H)
Motor : EM150 / EM300H / Brushless

Propeller : EDF2030X5

Battery Required : 8N300~600mAh(NI-MH)

Servo : PICO / NARO

Receiver : R4PII / R6NII

Speed controller : ICS-300 above

Radio Required : 4-Channel radio



  • GW/A10-EDF55-150/G (Green color )

  • GW/A10-EDF55-150/D (Desert color)

  • GW/A10-EDF55-150/G8 (Gray color)

  • GW/A10-EDF55-300H/G (Green color)

  • GW/A10-EDF55-300H/D (Desert color)

  • GW/A10-EDF55-300H/G8 (Gray color)



W/ EDF55-150 or EDF55-300H Duct Fan power system set.

ICS-480 above for EDF55-300H power system

W/ EDF50 Duct Fan power system set.



AIRPLANE MANUAL _ A10AIRPLANE MANUAL _ A10 EDP100/300H (2)AIRPLANE MANUAL _ A10 EDP100/300H (2)PRODUCT ALBUM零件價目表

GW/A10-EDP Series ( THE WARTHOG)

Length : 872 mm (34.3 in.)

Wing Span : 968 mm (38.1 in)

Wing Area : 13.95 dm (216 sq.in)

Empty Weight :

Flying Weight : 470~520 g (16.6~18.3 oz)

Wing Loading : 31.50~35.80 g/dm²  (10.3~11.7oz/sq.ft)

Power System : EDP150 / EDP300H x2

Propeller : EP5030 / EP4530 / EP4025

Battery Required : 6N400mAh(NI-CD) /7~8N500mAh(NI-MH) above

Servo : PICO / NARO

Receiver : R4PII / R6NII

Speed controller : ICS-300 above

Radio Required : 3~4-Channel radio

  • GW/A10-EDP150/G (Green color)

  • GW/A10-EDP150/D (Desert color)

  • GW/A10-EDP150/G8 (Gray color)

  • GW/A10-EDP300H/G (Green color)

  • GW/A10-EDP300H/D (Desert color)

  • GW/A10-EDP300H/G8 (Gray color)

W/ EDP150 or EDP300H power system set and propeller.

AIRPLANE MANUAL _ A10 EDPPRODUCT ALBUM







A10 Media Play

NOTE

  Video-1

Capacity : 1,245k    Time : 1:14

Outdoor Fly show
  Video-2

Capacity : 1,090k    Time : 1:08

Outdoor Fly show
  Video-3

Capacity : 3,108k    Time : 0:51

Outdoor Fly show
  Video-4

Capacity :    564k    Time : 0:09

Outdoor Fly show
