Length : 1100mm (43.3 in) Wing Span : 1080 mm (42.5 in) Wing Area : 23.8dm² (368.9 sq in) Empty Weight : 309 g (10.9 oz) Flying Weight : 720 g (25.4 oz) Wing Loading : 30.20 g /dm² (9.9 oz/sq.ft) Power System : EPSD350/C (optional) Propeller : HD1260 (optional) Battery Required : 3S1P Li-Po 2200 mAh above Servo : MICRO , MINI , PARK *4~6 Receiver : R6NII / RD8SL / R8MSL / R8MSL+ Speed controller : ICS-600Li above Radio Required : 4-6 Channel radio
|
Features: 1. It's powered by GWS 3014 outrunner + 3-blade prop.EP1060x3 with more thrust. 2.Its landing gear comes with spring for absorbing shock. 3.It comes with adjustable push rod connectors, easy to apply and adjust. 4. Bigger air intake applied on cowl for better cooling. The coming new landing gear GWRGP003 (not included in the kit) can decrease its drag significantly in the air. Kit includes: 1. GWBLM007 3014 outrunner motor………...…………1pcs 2. Propeller EP1060x3 (3-blade) ………….............……1pcs 3. Motor shaft adapter(GWADP005) Φ5-M6…….......….1pcs 4.GWEMM002 38MM Motor Mount……………………...1pcs 5.Adjustable push rod connector ……………….........…4pcs |
) |
) |
) |
) |
) |
) |
) |
) |
