Brushless Motor



GWBLO2205 (100% CNC)



2205/15T <NO LOAD>

MODEL

Voltage

NO   LOAD

KV

DIMENSIONS

WEIGHT

CURRENT (A)

SPEED (rpm)

SHAFT (mm)

APPEARANCE
(mm)

g

oz

GWBLO2205

7.4

0.7

15984

2160

3

28

27.2

0.96



< Performance Reports with GWS Propellers >



PROPELLER

Volts (V)

Amps (A)

Thrust

Power (W)

Efficiency





g

oz

g/w

oz/kw

RPM

EP-4540

7.4

4.2

139

4.9

31.08

4.47

157.74

36

14190

11.1

7.8

274

9.66

86.58

3.16

111.62

41

19860

EP-5030

7.4

4.3

170

6

31.82

5.34

188.43

39

14280

11.1

8.8

293

10.33

97.68

3

105.8

42

19370

EP-5043

7.4

5.9

203

7.16

43.66

4.65

163.99

42

13380

8.4

7

241

8.5

58.8

4.1

144.56

39

14670

9.6

8.5

285

10.05

81.6

3.49

123.19

45

16320

11.1

10.3

364

12.84

114.33

3.18

112.29

50

18480

EP-6030

7.4

6.1

247

8.71

45.14

5.47

192.99

38

13180

8.4

7.4

295

10.4

62.16

4.75

167.38

43

14430

9.6

9.7

330

11.64

93.12

3.54

124.99

48

15630

11.1

15

327

11.53

166.5

1.96

69.27

55

15510

EP-7035

7.4

8.2

328

11.57

60.68

5.41

190.65

43

12030

8.4

9.8

395

13.93

82.32

4.8

169.24

46

13140

9.6

12.2

474

16.72

117.12

4.05

142.74

55

15360

11.1

14.1

562

19.82

156.51

3.59

126.65

66

15540

EP-8040

7.4

10.4

380

13.4

76.96

4.94

174.15

51

8880

8.4

12.6

451

15.91

105.84

4.26

150.29

62

9750





GWS 2205/15T Brushless Motor Instructions︰
Be sure to follow the notes as below:
1. Its KV value is 2050.
2. Never let it run continually for over than 5 minutes when its power reaches 90W.
Never let it run continually for over than 10 seconds when its power reaches 140W.
3. It is recommended to use this motor on 3D airplane with its total flying weight less than 350g (12.36 oz).
4. It is required to keep good ventilation for this motor during its running hours.
5. This motor could not work when its temperature goes higher than 70C (158F )
6. Its temperature will go higher than 40C (104F ) very quickly when its power reaches 90W.
7. Using propeller longer than 8040 (8"x4") on this motor is not recommended, this motor has been tested to work well with 2S 7.4V Li-Po battery pack, and it is strongly recommended to use only 2S 7.4V Li-Po battery pack with this motor.
8. It is not recommended to reach current drawing over than 12A when 2S 7.4V LiPo battery pack is applied with this motor.

Extra note needs to be taken seriously:
It is Strongly Recommended to Take Great Care when using propeller size in 8043 (8"x4.3") on this motor as the current (Amp.)
drawing would be over than its Maximum Limitation quickly when high R.P.M. applied.



Please refer to the user's manual for detail : GWBLO2205
