GW/EDF50 ELECTRIC DUCTED FAN POWER SYSTEM


GWEDF050D EDF50-BL2018-3/Blue (EP2030*3)
GWEDF050DA EDF50 (EP2030*3) Motor not included

GWEDF050E EDF50-BL2018-3/Blue (EP2030*5)
GWEDF050EA EDF50 (EP2030*5) Motor not included

WEIGHT : 29.81~29.98 g (1.05 oz)

Feature : High efficiency, High output, Ultra-light, High speed Small


ITEM : GW/EDF50

MOTOR : CN12-RLC  / CN12-RXC

WEIGHT : 29.81~29.98 g (1.05 oz)

Feature : High efficiency, High output, Ultra-light, High speed Small
Click here photo to view
Click here to view Click here to view Click here to view

POWERED BY BRUSHLESS MOTOR

GW/EDF050D (EDF2030X3) with BL2018 5800KV

Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)

7.4

7.6

153

5.40

56.24

2.72

95.95

11.1

14.3

298

10.51

158.73

1.88

66.22

GW/EDF050E (EDF2030X5) with BL2018 5800KV

Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)

7.4

11.6

246

8.68

85.84

2.87

 101.08

11.1

21.5

399

14.07

238.65

1.67

58.97

GW/EDF-50     MOTOR : CN12-RLC  ( With DUCT)

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2020X3

6

2.62

54

1.91

15.72

3.44

 121
EDF2020X3

7.2

3.39

72

2.54

24.41

2.95

 104

WITH DUCT AND INTAKE RING

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2020X3

6

2.62

67

2.36

15.72

4.26

 150
EDF2020X3

7.2

3.4

82

2.89

24.48

3.35

 118

　

GW/EDF-50A    MOTOR : CN12-RLC   ( With DUCT)

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X3

6

3.34

56

1.98

20.04

2.79

 99
EDF2030X3

7.2

4.20

74

2.61

30.24

2.45

 86

WITH DUCT AND INTAKE RING

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X3

6

3.35

76

2.68

20.10

3.78

 133
EDF2030X3 7.2 4.20 97 3.42 30.24 3.21 113

　

GW/EDF-50B    MOTOR : CN12-RLC   ( With DUCT)

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X5

6

4.00

61

2.15

24.00

2.54

 90
EDF2030X5

7.2

4.90

78

2.75

35.28

2.21

 78

WITH DUCT AND INTAKE RING

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X5

6

3.90

79

2.79

23.40

3.38

 119
EDF2030X5

7.2

4.93

98

3.46

35.50

2.76

 97

　

GW/EDF-50H     MOTOR : CN12-RXC  ( With DUCT)

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2020X3

9.6

1.35

53

1.87

12.96

4.09

 144
EDF2020X3

10.8

1.5

63

2.22

16.20

3.89

 137

WITH DUCT AND INTAKE RING

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2020X3

9.6

1.34

57

2.01

12.86

4.43

 156
EDF2020X3

10.8

1.59

75

2.65

17.17

4.37

 154

　

GW/EDF-50AH  MOTOR : CN12-RXC   ( With DUCT)

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X3

9.6

1.76

59

2.08

16.90

3.49

 123
EDF2030X3

10.8

2.12

70

2.47

22.90

3.06

 108

WITH DUCT AND INTAKE RING

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X3

9.6

1.85

75

2.65

17.76

4.22

 149
EDF2030X3

10.8

2.16

90

3.17

23.33

3.86

 136

　

GW/EDF-50BH MOTOR : CN12-RXC   ( With DUCT)

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X5

9.6

2.16

64

2.26

20.74

3.09

 109
EDF2030X5

10.8

2.51

77

2.72

27.11

2.84

 100

WITH DUCT AND INTAKE RING

ROTOR Volts (v) Amps (A) Thrust Power (w) Efficiency
(g) (oz) (g/w) (oz/kw)
EDF2030X5

9.6

2.15

84

2.96

20.64

4.07

 144
EDF2030X5

10.8

2.54

97

3.42

27.43

3.54

 125
